Portrait is a reliable manufacturing system, capable of producing end-use parts in a wide variety of materials. Its solid steel structure, quality components and careful design result in a high uptime with low maintenance costs.
Our dual extruder solution permits printing more complex objects with a better surface finish. Achieve high speed without sacrificing print accuracy.
Although open to using third-party filament, Portrait’s cartridges and enclosed chamber prevent KODAK 3D Printing Filament from absorbing humidity or dust, while enabling our sensors and software to fully control the printing process.
Safe and transparent, the Portrait’s built-in camera, multi-language touchscreen and full connectivity gives you remote supervision of your device and of user activity.
Controls the printing environment and reduces warping when printing large objects.
Interior color lighting indicates the printer’s state and any need of user intervention, even at a distance.
with optional continuation from the second extruder.
Air filtration system eliminates odors and microscopic particles. A secondary thermistor prevents the hotends from overheating.
Wi-Fi, USB pendrive and a great integration with email, file sharing services and social networks.
Online resources, troubleshooting guides, replacement parts and knowledgeable technical assistance.
|Print volume||200 x 200 x 250 mm / 8" x 8" x 10"|
|Extruders||Dual extruders with tilting nozzles, available in different sizes and materials with quick exchange mechanism|
|Chamber||Fully enclosed with temperature monitoring
Smoothieboard 5XC, 32 bit
|Screen||Multi-language color touch screen
5” HDMI screen, 800x480 resolution
|Connectivity||Wi-Fi, USB pendrive, multi-user features and integration with email, file sharing services and social networks|
|Calibration and leveling||Automatic|
|Internal lights||Color LEDs, indicate printer status|
|End-of-filament sensor||With optional continuation from the second extruder|
|Processors||Raspberry Pi 3 Smoothieboard 5XC, 32 bit|
|Filament compatibility||Open to third party filament, with 2 hermetically closed cases for KODAK 3D Printing Filament|
|Power supply||12V 30A 300W switching, selectable 110V / 220V|
|Physical dimensions||455 x 433 x 451 mm / 18" x 17" x 18"|
|Weight||27 Kg / 60 Lbs|
|All specifications are subject to change in the final product|
